Prairie Compact – 1000-2500L

Prairie Compact Overview

The Prairie Compact incorporates many elements from the larger Goldacres trailing sprayer range to ensure maximum strength, longevity and performance.

Typical uses

Features 1000L 1500L 2000L 2500L
Broadacre spraying
Rowcrop spraying
Vegetable spraying
Horticultural spraying
Weed control
Pest control
Industrial spraying
Municipal spraying
Contracting
Specialised cleaning
Inoculant spraying
Fertiliser application
Fire Fighting
Water transfer
Irrigation
Washdown



Features
Features

Pressure manifold control station
The pressure manifold control station clearly places all the functions in the one convenient location. All valves are colour coded and clearly labelled for easy identification and operation.

Udor Zeta 85
Udor Zeta 85 features chemical resistant components such as desmopan for the pump diaphragms and stainless internal components ensuring great pump life. Available as pto or hydraulic driven option.

Suction filter
A high flow suction filter with 50 mesh screen is plumbed with a 3 way ball valve to allow suction from fresh water tank.

Spray pressure gauge
Centrally mounted with large face the pressure gauge allows the operator to keep an eye on system pressure easily.

Chassis
RHS construction, engineered for Aussie conditions.

Axle
Width adjustable reinforced with 8 stud hubs and 14.9 x 24 wheels.

Specifications
Feature 1000L 1500L 2000L 2500L
Tank capacity 1000L 1500L 2000L 2500L
Flush tank 45L
Boom 10m manual Cross folding – standard 10m manual Cross folding – option
10m manual Crossover Twinlink – option
12m manual Crossover Twinlink – option
Boom options 22L Foam marker
Single sided manual or electric fenceline nozzle
Boom suspension & control N/A Manual boom height adjustment – option
Hydraulic boom height adjustment – option
Twin link levelling – option
Chemical Induction probe – standard
Induction N/A 40L Induction hopper – option
Chemical induction probe – standard
Controls 3 section electric – standard
Raven SCS440 – option
Pump Zeta 70 pto – standard

Honda GX200 pull start with Zeta 85 pump – option

Zeta 85 pto – standard
Zeta 85 hydraulic – option
Filtration Suction – 50 mesh screen
Pressure – 100 mesh screen
Hose reel N/A 30m hose reel with AA30 gunjet – option
Wheel & axle Single axle, 16″ wheels & leaf suspension Wheel 14.9 x 24 with manual width adjustable axle – option Single axle, 16″ wheels & leaf suspension – option
Wheel 14.9 x 24 with manual width adjustable axle – option



  • 2000L Prairie Compact
  • 1000L Prairie Compact
